Vacuum belting uses holes, slots, or machined channels to connect a product-facing belt surface with a vacuum chamber. Airflow through the belt creates a pressure difference that holds lightweight, thin, unstable, or precisely positioned products during conveying.

Vacuum belts are used for paper, film, pouches, cartons, labels, food products, electronic components, and automated handling. They may be flat conveyor belts, timing belts, coated feeder belts, or specially engineered modular belts. This guide compares the main types, materials, applications, benefits, limitations, and specification details.

Key Takeaways

Vacuum belting holds products by drawing air through engineered perforations.
Flat, timing, coated, modular, and feeder belts serve different motion requirements.
Hole patterns must align with vacuum channels without damaging tensile members.
Product leakage, belt tracking, blower capacity, and release points determine performance.

What Is Vacuum Belting?

Vacuum belting is a category of conveyor or machine belt modified to transmit suction through its body. Perforations in the belt pass over slots, grooves, or ports in a stationary vacuum bed. A blower or pump removes air from the chamber, creating lower pressure beneath the product than in the surrounding atmosphere.

The pressure difference pushes the product against the belt. The belt then carries it through a horizontal, inclined, vertical, or inverted path, depending on the available holding force and machine design. Vacuum does not pull in a mysterious mechanical sense; atmospheric pressure supplies the clamping force when air is removed beneath the product.

Dorner describes vacuum conveyors as perforated belts running over custom bed plates with vacuum chambers. Its engineers select belt type, hole spacing, pattern, and size for the product and application (Dorner, Vacuum Belt Conveyors, 2026).

How Does a Vacuum Belt Work?

A vacuum belt operates as one part of a complete air-handling and conveying system. The belt moves over a low-friction bed containing longitudinal grooves or localized ports. The belt holes repeatedly pass over those openings, connecting the product contact area to a plenum supplied by a blower or vacuum pump.

When a product covers one or more holes, airflow beneath it is restricted and pressure drops. Atmospheric pressure pushes the product toward the belt. Uncovered holes remain leakage paths, so the system must supply enough airflow to maintain useful pressure while products enter, leave, or vary in size.

Vacuum zones can cover the full conveyor length or only selected process areas. Separate chambers can provide stronger holding near acceleration, inspection, printing, or elevation changes and reduced suction near discharge. Controlled release is important because excessive holding at the conveyor end can delay separation or pull flexible material around the return.

The belt must track accurately so its holes remain above the vacuum channels. V-guides, crowned pulleys, flanges, tracking rollers, or timing teeth may control lateral position. Dorner notes that vacuum conveyors use perforated belts and grooved bed plates, while blower capacity depends on total hole area and required holding pressure (Dorner, Moving Along with High-Tech Conveyor Systems, 2015).

What Are the Main Types of Vacuum Belts?

The main types are perforated flat belts, vacuum timing belts, covered vacuum belts, modular plastic vacuum belts, and feeder belts. They differ in motion accuracy, flexibility, available backing thickness, perforation method, cleaning, and compatibility with vacuum beds or pulleys.

Perforated Flat Conveyor Belts

Flat vacuum belts are fabric-reinforced PU, PVC, or elastomer belts with holes arranged over vacuum grooves. They provide a broad, continuous supporting surface and can handle paper, film, cardboard, pouches, fabrics, plastic parts, and light packages.

Vacuum Timing Belts

Vacuum timing belts combine synchronous motion with suction. They are used when each product must remain at a controlled position relative to machine tooling, sensors, printing heads, cutters, or pick-and-place equipment. The teeth engage matching pulleys while machined holes connect the belt back to vacuum channels.

Polyurethane timing belts can be manufactured with special cord spacing to create safe perforation zones. Megadyne asks for hole diameter, pattern, tolerances, and a dimensioned sketch, and notes that special cord spacing can prevent tensile cords from being cut (Megadyne, How to Get the Right Belt the First Time, 2025).

Coated or Covered Vacuum Belts

A cover modifies friction, compressibility, release, wear, or product contact. Common surfaces include polyurethane, rubber, foam, silicone, and specialty elastomers. Grooves can be machined into the cover to distribute suction laterally from each hole.

Soft covers can improve sealing against uneven products, but they may compress, wear, or mark easily. Thick covers increase minimum pulley diameter and may retain heat during repeated flexing. BRECOflex offers backing grinding, slitting, grooves, and perforations for vacuum applications, with machining options depending on cover thickness and construction (BRECOflex, Custom Timing Belt Options, 2026).

Modular Plastic Vacuum Belts

Selected modular plastic belts use closed or semi-closed top surfaces with engineered perforations connected to a plenum. Replaceable modules and positive sprocket drive can suit wide conveyors, wet environments, or layouts where fabric belts are difficult to maintain.

Feeder and Folder-Gluer Belts

Feeder belts use holes and surface grooves to pick, separate, accelerate, and position paperboard, envelopes, cartons, and sheets. Multiple narrow belts may run in parallel, each aligned with vacuum ports. High-friction or non-marking covers help grip products during rapid starts.

Megadyne describes a corrugated-equipment timing belt with ground teeth, machined cover slots, and vacuum holes. The construction used a non-marking neoprene cover and controlled machining tolerances for paperboard handling (Megadyne, Automated Paperboard Feeder Belt, 2017).

Which Materials Are Used for Vacuum Belting?

Material selection affects flexibility, wear, sealing, friction, temperature, chemical resistance, cleanliness, static behavior, and machining. The belt body and product-facing cover may use different materials, so the complete construction should be specified rather than naming one polymer.

Belt Material	Main Strengths	Typical Vacuum Uses	Main Limitations
PU or TPU	Abrasion resistance, flexible fabrication, food and antistatic options	Flat belts, timing belts, packaging, automation	Hydrolysis, heat, and chemical limits vary
PVC	Economical, broad surface choices, easy fabrication	Paper, cartons, pouches, general conveying	Temperature, plasticizer, and chemical limits vary
Rubber or neoprene	Grip, damping, durable feeder covers	Corrugated board, printing, folder-gluer machines	Weight, marking, oil, and aging depend on compound
Silicone	Release, softness, useful temperature capability	Food, film, delicate or warm products	Lower tear and abrasion resistance in many grades
Modular plastic	Replaceable modules and positive drive	Wide, wet, or special-purpose vacuum conveyors	Joint leakage and chamber sealing require review

PU and TPU are common where accurate machining, abrasion resistance, or synchronous motion is needed. Thermoplastic constructions can be welded or fabricated, while special cord layouts support perforation. Food-contact, hydrolysis-resistant, antistatic, or detectable grades are available for selected applications.

Electrical behavior matters with paper, film, textiles, and electronics. Moving belts and dry products can generate static charge. Dorner lists electrically conductive belting for thin products such as paper, light cardboard, cloth, and plastic film in vacuum conveyor applications (Dorner, Vacuum Belt Conveyor Specifications, 2014).

Where Is Vacuum Belting Used?

Vacuum belting is used when gravity, friction, or side guides cannot hold a product reliably. It is especially effective for thin sheets, flexible packaging, lightweight parts, vertical transport, inverted conveying, and processes requiring a flat, repeatable product position.

Packaging and Printing

Packaging machines use vacuum belts to feed cartons, labels, leaflets, pouches, and web materials through printing, coding, sealing, folding, cutting, and inspection stations. Timing belts support indexed movement, while flat belts suit continuous transport.

Holding the product flat improves print registration and sensor consistency. The vacuum zone should end before the required release point, and the surface must avoid marking printed graphics. BRECOflex identifies grooves and perforations as common belt features in paper and printing applications (BRECOflex, Paper and Printing Industry Solutions, 2026).

Paper and Envelope Handling

Paper feeders use suction to separate sheets, stabilize envelopes, and control lightweight material during acceleration. Several narrow perforated belts can create distributed grip while leaving space for rollers, sensors, or folding tools.

Food Processing

Food applications include holding bakery pieces, confectionery, wrappers, pouches, and lightweight packaged products. Vacuum can stabilize products on inclines or maintain position during cutting, inspection, and transfer. The belt and vacuum bed must suit food contact, temperature, cleaning chemicals, and sanitation access.

Perforations can expose internal fabric or tensile cords if the belt is not designed for machining. Sealed edges, clean hole walls, drainable plenums, and controlled cleaning are important. BRECOflex offers tension-free zones for perforated timing belts used in food and beverage applications (BRECOflex, Food and Beverage Industry Solutions, 2026).

Electronics and Automation

Automation systems use vacuum belts for circuit boards, wafers, films, foils, labels, and small molded parts. Synchronous belts maintain registration with machine cycles, while vacuum prevents parts from shifting during inspection, printing, or robotic pickup.

Sheet and Film Transport

Plastic film, textiles, foil, cardboard, and composite sheets can flutter, wrinkle, or lift at speed. Vacuum distributes holding force across the product without side clamps. Multiple zones can keep the material flat during measurement, cutting, coating, lamination, or visual inspection.

What Are the Benefits and Limitations?

Vacuum belting holds lightweight products without mechanical clamps. It can stabilize sheets, maintain orientation, improve print or cut registration, support elevation changes, and transport products vertically or upside down. Suction can also reduce the need for side guides that might scratch or distort delicate material.

The main limitation is leakage. Uncovered holes, porous products, worn bed seals, misaligned perforations, and open belt joints reduce pressure. Increasing blower size raises energy use, noise, and heat but may not solve poor sealing or an unsuitable pattern.

Perforation can weaken tensile members or create crack initiation points. Hole edges, spacing, countersinks, cover thickness, cord layout, and splice position require engineering approval. A standard belt drilled in the workshop may track poorly, fail early, or provide inconsistent suction.

Vacuum holding also changes during product entry and release. A part may not cover enough holes at pickup, or it may remain attached beyond the intended discharge. Testing should include minimum and maximum products, gaps in flow, porous materials, speed changes, starts, stops, and a partially blocked belt.

How Is Vacuum Belting Specified?

Begin with the product. Record length, width, thickness, weight, material, porosity, stiffness, surface condition, temperature, orientation, and whether marking is acceptable. Define acceleration, speed, incline, process forces, and the exact area where holding is required.

Specify the belt construction, including profile, width, endless length, thickness, tensile member, cover material, cover hardness, surface finish, splice, tracking method, and pulley or sprocket geometry. For timing belts, include pitch, tooth profile, tooth count, and pulley details.

Provide a dimensioned perforation drawing. State hole diameter or slot dimensions, row spacing, pitch, edge distance, pattern origin, tolerances, countersink, grooves, and relationship to the splice, timing teeth, tensile cords, and tracking guides. Megadyne specifically recommends a drawing with the hole pattern and tolerances for vacuum modifications (Megadyne, How to Get the Right Belt the First Time, 2025).

Define the vacuum system separately. Include chamber length and width, number of zones, groove pattern, port size, target pressure, required airflow, vacuum source, filter, controls, venting, and release location. The blower should be selected from measured or estimated leakage as well as theoretical product force.

Finally, validate the complete assembly. Check product pickup, holding, flatness, registration, release, belt tracking, hole alignment, noise, temperature, drive load, and blockage sensitivity. Record the accepted belt drawing and chamber settings so a replacement belt reproduces the original performance.

Frequently Asked Questions

What is a vacuum conveyor belt?

A vacuum conveyor belt is a perforated belt that runs over a chamber connected to a vacuum source. Air drawn through the holes creates a pressure difference that holds products against the belt during horizontal, inclined, vertical, or inverted conveying.

Can any conveyor belt be perforated for vacuum use?

No. Hole placement can cut fabric layers, tensile cords, tracking guides, or timing-belt reinforcement. The belt must also remain strong, flexible, trackable, and compatible with the vacuum bed. Use a construction approved for the required perforation pattern.

Is more vacuum always better?

No. Excessive vacuum can increase belt drag, energy use, noise, product marking, and release difficulty. The system needs enough pressure and airflow for the worst product and leakage condition, with zones and controls that release the product at the correct point.

What is the difference between vacuum pressure and airflow?

Pressure difference creates theoretical holding force, while airflow replaces air lost through leakage. A well-sealed product may need pressure with modest flow. Porous products or many uncovered holes need more airflow to maintain that pressure.

How are vacuum belt holes kept aligned?

Alignment can use V-guides, crowned pulleys, tracking rollers, pulley flanges, or timing teeth. The chosen method must keep every perforation over the bed grooves or pulley ports throughout operation without adding unacceptable wear or deformation.

Conclusion

Vacuum belting combines a moving belt with engineered perforations, a chamber, and a vacuum source to hold products in position. Flat, timing, coated, modular, and feeder belts each suit different motion, sealing, and process requirements.

Successful selection depends on the complete air path. Define the product, belt construction, hole pattern, cord layout, vacuum zones, pressure, airflow, tracking, and release point together. A validated drawing and production trial provide more reliable results than drilling a standard belt and increasing blower power afterward.
